Main Operation Condition

Value	Unit	Item
80	◦C	Temperature
100	atm	Pressure

Product Specification

Value	Unit	Item
50-70	ppm	Total Sulphur
50	ppm	Total Mercaptan

Feed Specification

Value	Unit	Item
1460	ppm	Total Sulphur
533	ppm	Total Mercaptan

The Schematic And Specification Of The Proposed Reactor And Catalysts

Reactor Design Properties
Value	Unit	Item
Stainless Steel 316	Material
5	Ton/Batch	Capacity
2550	mm	Internal Diameter
4800	mm	Hight (TL TL)

Design Catalysts
Weight (Kg	Material Name	Bed No)
1800	R-1401-A	1
2400	R-1401-B	2
1800	R-1401-C	3

Proposed Catalysts

Proposed Catalyst For 1 st Bed (R-1401-A)
Value		Unit	Properties
R-1401-A		—	Type
String		—	Shape
	30	mm	External Diameter
	Bore Diameter		Size
	30		Length
Chemical Composition
Al2O3		wt %	48Al2O3
38			SiO2
Physical Composition
0.95		Kg/m³	Density
50≥		m²/Gr	Surface Area
70≥		N	Crush strength

Proposed Catalyst For 2 st Bed (R-1401-B)
Value		Unit	Properties
R-1401-B		—	Type
Shape		—	String
Size	External Diameter	mm	5
	1.5		Bore Diameter
	5		Length
Chemical Composition
42		wt %	Tungsten
19			Alumina
Physical Composition
1.2		Kg/m³	Density
≥ 60		m²/Gr	Surface Area
≥ 70		N	Crush strength

Proposed Catalyst For 3 st Bed (R-1401-C)
Value		Unit	Properties
R-1401-C		—	Type
Disordered		—	Shape
Size	15	mm	External Diameter
	6		Bore Diameter
	15		Length
Chemical Composition
3		wt %	Titanium
30			Alumina
Physical Composition
0.95		Kg/m³	Density
≥ 50		m²/Gr	Surface Area
≥ 70		N	Crush strength
